Outdoor Advertising P6 LED Video Wall Dimension Customized High Brightness

Ask Lasest Price
Brand Name :	ABT
Model Number :	P6
Certification :	FCC,CE,UL,ROSH,ISO9001
Price :	USD800-USD1100 for square meter
Payment Terms :	T/T, Western Union, MoneyGram
Supply Ability :	1500square meter/month
Delivery Time :	7-15days

Add to Cart

Product Details
Company Profile

Outdoor Advertising P6 LED Video Wall Dimension Customized High Brightness

Full color led display outdoor advertising P6 led billboard

Product Advantages:

1. Brightness uniformity less then 5%, and the maximum uniformity can reach 1%
2. On line pixel inspection function : inspect each disabled pixel and remote transmission
3. Automatic brightness adjustment: adjust the brightness of the screen according to the ambient brightness, thus avoiding the waste of brightness and reducing power consumption
4. Large horizontal and vertical viewing angle
5. Led module can remain constant in the hight and low temperature environment
6. Gray scale of 16 bits, and contrast of 1000:1
7. No water standing and no dust accumulating
8. Use the switching power supply with the efficiency of more than 85%, and provide the correction function with the power factor of more than 0.95, thus reducing power consumption of the power supply
9. Use upgraded full color control system
10. Energy saving and environment protection

Product Parameters

Item	P6 Outdoor LED Display
Model Number	P6
Pixel Pitch	6mm
Pixel Density(dots/m²)	27777
Pixel Configuration	3 in 1
LED Type	SMD3535
Module size(mm)	192*192
Module Resolution(dots)	32*32
Min.Viewing Distance(m)	≥6
Brightness(cd/m²)	≥5500
Viewing Angle(degree)	≤140°
Average Power Consumption(w/m²)	550-850
Scan Mode	1/8
Protection Level	IP65
Cabinet Size(mm)	960*960
Color Temperature	The brightness of R.G.B.is adjustable according to software 100level;Color temperature is adjustable in terms of detailed requirements
Input Voltage	AC220 V/50HZ or AC 110V/60HZ
Refresh Rate	LED screen refresh frame frequency recommended is no less than 1200HZ(recommended)
Color	64g color(on the condition of 4096 gray scale)
Horizontal/Vertical viewing angle	<120°
Gray Scale	Recommended 14BIT
Effective Communication Distance(without relay)	Unshielded twisted-pair net line transmission distance is 100 meters,max transmission distance is 130 meters.

Our Services

Quality Guarantee
Warrant time is 2 years, during this period; we will maintain and replace the defect components for free, if the damage is caused by fault operation, you need to pay for cost. After warranty time is over, we will offer you component parts at our bottom cost

Technical Support
We provide technology training for free, which contains the operation and maintenance training of the LED screens in the factory. All operation manual, software, test reports are available. Any associated CAD drawing on how to fix up the display and some other expert suggestion will be provided. If need, we can send our engineer to your side for instruction, and clients should pay the cost about engineer’s trip.

Free Training
You can send your engineers to our factory for one week free of charge training, such as: soft operation,led video processor configure,installation, adjustment, basic repairing and so on.
