Features:
1. High brightness and automatic adjustment;
2. Power saving compared with common products;
3. Using virtual pixels, better viewing effect;
4. larger viewing angle: Horizontal angle 160 degree/elevation
angle 70 degree.
Specifications
LED Module |
Resolution | 32(H)×16(V) |
Pitch | 8mm |
Density | 15625pixels/m2 |
LED Arrangement | SMD3535 3IN1 |
Driver Mode | Dynamic 1/4 Duty constant current |
Size | 256mm×128mm |
Mask | Pure Black mask-high contrast screen |
LED Cabinet |
Cabinet Size | 768mm,1024mm,1280mm are Avaliable |
Cabinet Material | Steel or Aluminum |
Weight | About 45 kg/m2 |
Electricity Parameter |
Optical Ratings |
Brightness | ≥6500cd/m2 |
View Angle | 140 degree ( horizontal) 140degree(vertical) |
View Distance | 8m-80m |
Gray Scale | 8bits input, correction with 14bits |
Display Color | 16.7M |
Brightness Adjustment | 100 levels |
Power Supply |
Operation Power | AC100-240V 50-60HZ Switch-able |
Maxim Power Consumption | 800 W/m2 |
Average Power Consumption | 500 W/m2 |
Control System |
Correction Scale Level | 16bits |
Frame Update Frequency | 60Hz |
Screen Refresh Frequency | 1920Hz |
Gamma Correction | -5.0—5.0 |
Support Input | Composite Video, S-Video, DVI, HDMI., SDI, HD_SDI |
Control Distance | Ethernet cable 100m, optical fiber 5km |
Support VGA Mode | 800×600,1024×768,1280×1024,1600×1200 |
Color Temperature | 5000-9300 adjustable |
Brightness Correction | dot by dot, module by module, cabinet by cabinet |
Reliability |
Operating Temp. | -20-60 Celsius degree |
Operating Humidity | 10-95% RH |
Operating Life | 100,000 hours |
MTBF | 5000 hours |
Continuous Working Time | ≥48 hours |
Protection Level | IP65 Waterproof |
Out of Control Pixel Rate | 0.01% |
Our Services
1)Reply your inquiry in 24 working hours.
2)Experienced staffs answer all your query in fluent
English,Spanish,French,German etc
3)Customized design is available,OEM & ODM are welcomed.
4)Exclusive and unique solution can be provided to our customer by
our well-trained and professional engineers and staffs.
5)Special discount and protection of sales area provided to our
distributor.
6)Warmly welcome your visit in our company if available.
7)Warranty: 24 months, a little investment for longer warranty
time.
FAQ:
1. Are you factory?
Yes, we have very rich experience in production and development.
you will got better service and delivery on time.
2. How is your delivery time?
We delivery as contract on time, All kinds of led module have in
stock. We will be fine as compensation.
3. What is your products packing?
We provide 3 kinds of packing case: carton paper case,wooden
packing case and flight packing case.
Carton paper case for led module
Wooden packing case for heavy iron cabinet
Flight packing case for rental aluminum die-casting cabinet
4. Quality gurantee:
Life span of LED display screens is more than 100,000 hours
All our LED displays have CE,FCC,RoHS certificates.
5. Prompt &Professional service :
