Full color IP65 waterproof P6 SMD outdoor LED advertising display
screen
Product Description
Features of p6 outdoor full color led screen display for
advertising led video wall:
1. High quality LED chip and high anti-static electricity capacity.
2. Large viewing angle and smooth displaying provide excellent
visual effect from every angle.
3. The integration of lamp and driving IC, together with with the
multi-circuit structure, achieves evenly-distributed current, low power consumption and fast heat dissipation.
4. Ultra-high brightness, low attenuation, high reliability and
weather ability.
5. High contrast ratio. Adopting black lamps can improve the
contrast ratio by 50%.
6. High refresh rate, high gray scale, ghost-canceling, low power
consumption, low EMI, anti-creeping, multi-route redundancy backup-supporting, and
dot-by-dot-calibration.
Application :
Widely applied to traffic information distribution of station, quay
and qirport, conference, shoppingmall, brand presentation, TVstation, stage show, concert and so on.
Specification for outdoor P6mm LED display
| List | Item | Description |
| 1 | Pixel Pitch | 6mm |
| 2 | Module Size | 192*192mm |
| 3 | Pixel Density | 27777/s.q.m |
| 4 | Pixel composition | 1R1G1B |
| 5 | LED Type | 3535 |
| 6 | Module Resolution | 32*32 |
| 7 | Power Consumption of Module | 30W |
| 8 | Maximum Power Consumption | 750W/ s.q.m |
| 9 | Cabinet Size | 960*960mm |
| 10 | Cabinet Resolution | 160*160 |
| 11 | Cabinet Weight | 40Kg Water-proof |
| 12 | Driving Method | 1/8Scan Constant Current Driving |
| 13 | White Balance Luminance(CD/ s.q.m) | ≥7000cd/ s.q.m |
| 14 | Operating Environment Temperature | -20℃—60℃ Optional |
| 15 | Operating Voltage | 220V±10% or 110V±10% |
| 16 | Control System | Sent card+DVI display card+receive card |
Trade Terms
1. Packing: Anti-shaking wooden cabinet /Air flight case/carton
2. Shipping port: Shenzhen. China
3. Shipping freights are quoted according to your requests
4. Delivery time:5-25 working days
5. 2 years warranty, lifelong maintaining.
After-sale service
1. Our products have two years warranty service ,lifetime free
maintenance and upgrade.
2. Complaint respond period not exceed 24 hours; maintenance
guidance and problem solution supplied in 48 hours.
3. We offered training to our customer who includes operating and
maintenance of our products.
4. In the Maintenance period of the LED screen body, free of all
maintenance charges; After Maintenance period, only charge the
material costs fees free of manual work fees.
5. Full set of documents free of charge, which including
installation guidance, software operation manual, easy maintenance
manual and control system software CD and so on.
6. If the users find any problem that cannot be solved, please
contact with our company, we can response in 24 hours. In order to
shorten the maintenance time, Our Company will deploy some spare
parts such as power and chips etc.
