RGB video panel P4.81 indoor led screen rental led display
Product Description
Features:
1. Ultra-Thin,Ultra light, Aluminum Alloy
frame(cabinet)--0.89kg/module, no more than 25.4kg/sqm;
2. Special Wall drape design, no need buy more structure for
installation;
3. Fast and front maintenance design, make your LED screen business
more proffessional and easier;
4. High refresh rate 3840Hz, 16bit Gray scale, high levels and
effect that able to be used at different Occasion;
5. Top Design: Smart/Auto function for inspect & tracking
temperature, Voltage, working time.
6. Concise wiring inside.
Details image:
Parameters:
| LED Module |
| Dimensions (w x h) | 250mmx250mm | Resolution (w x h) | 52 x 52 |
| Pixel pitch | 4.81mm | Pixel Density | 43264/m2 |
| LED Chip | Epistar | Pixel Configuration | SMD3528 |
| Standard Panel |
| Dimensions(w x h x d)(mm) | 500x 1000 x 70 | Module Quantity(pcs) | 8 |
| Physical Resolution (w x h)(dots) | 104 x 208 | Physical Pixels (dots) | 21,632/cabinet |
| Weight/Panel (kgs) | 12 | Material | die casting aluminum |
| Average Power/sqm (watts) | 160 | Max Power/sqm(watts) | 530 |
| Parameter | Value |
| Brightness | 2500cd/m2 |
| Viewing Angle | Horizontal 140 deg. Vertical 140 deg. |
| Minimum Viewing Distance | >4 meters |
| Brightness Control | 256 levels |
| Gray Scale | 16 bit |
| Refresh Rate | >1920Hz |
| Driving Mode | 1/13 Scan |
| Input Power Frequency | 50 or 60 Hertz |
| Input Voltage | 96-242 Volt |
| Blind Spot Rate | <1/10,000 |
| Lifetime at 50% Brightness | 100,000 hours |
| IP Rating | IP30 |
| Operating Temperature | -30 ~ +60 OC |
| Operating Humidity | 10% ~ 90% |
| Control Distance | CAT5 cable:<100 m; Single mode fiber:<10 km |
| Signal Input Format | AV, S-Video, VGA, DVI, YPbPr, HDMI, SDI |
| Operating System | Windows (2000/XP/Vista/7) |
FAQ:
1. Can you assign engineer to our site to guide the installation if
we require?
Yes. We have qualified and experienced engineers who are ready to
service for you.
2. How about your warranty and after-sale policy?
Two years warranty is free..
We provide 24 hour phone answering service and real-time remote
control service if you have any problem with our led screen.
3. How long time I can get the cargos after placing the order ?
Our production time is about 7~ 15 working days;
When we confirmed the order, after we get your deposit, we can
start production, we will update the production details in time;
Before finish, we will notice you and after we get full payment, we
can delivery the goods to you.
About the time from start port to destination, that depends on the
distance and the state of the sea company or airport company
4. What's the difference of DIP(1R1G1B) and DIP(3 in 1) ?
DIP(One LED, 3 in 1) LED Display, one pixel has one LED lamp, 3 led
chips in one LED Lamp;
Traditional DIP( 1R1G1B) use 3 LED Lamp in one pixel.
5. How I can make payment?
We support T/T, West Union and so on.
And about payment, we need you pay us 30% as deposit, for the rest
part, before delivery.
