Full color indoor P6 HD LED video display screen
Product Highlight:
1, Delicate Appearance,Fast and flexible installation
2, High-end display technology, the screen is more uniform and good
3, The use of the latest anti-collision plate technology guarantees
good security
4, Gap adjustable, seamless stitching,No noise, low power
consumption,Excellent thermal performance
5, Multi-function fixed, intelligent positioning, gap adjustable.
6, The entire screen seamlessly, can be quickly installed and
removed,Splicing gap flatness <0.1mm
Specifications:
| 576*576mm series |
|
| Pixel Pitch | 6mm | P3mm |
| Module Size | 192*192mm | 192*96mm |
| Pixel Density | 27777/㎡ | 111100/㎡ |
| Pixel composition | 1R1G1B |
| LED Type | SMD3528 | SMD2121 |
| The Optimum Viewing Angle | 140°/120° |
| Application | Indoor |
| Maximum Power Consumption | 750W/㎡ | 1200W/㎡ |
| Standard Cabinet Size | 576*576mm | 576*576mm |
| Cabinet Resolution | 96*96 | 192*192 |
| Cabinet Weight | 9Kg | 9Kg |
| Driving IC | MBI |
| Driving Method | 1/16 Scan | 1/32 Scan |
| Frame Frequency | ≥60Hz/s | ≥60Hz/s |
| Refresh Rate | ≥1500Hz/s | ≥1500Hz/s |
| White Balance Luminance(CD/㎡) | ≥1500cd/㎡ | ≥1500cd/㎡ |
| Operating Environment Temperature | -20℃—60℃ Optional | -20℃—60℃ Optional |
| Operating Voltage | 220V or 110V | 220V or 110V |
| Grey Scale | Display Colors≥16.7M | Display Colors≥16.7M |
| Brightness Adjustment | 1024 grades | 1024 grades |
| Input Signal | RF,S-Video RF, S-Vido, RGB, RGBHV, YUV etc. | RF,S-Video RF, S-Vido, RGB, RGBHV, YUV etc. |
| Control System | PC+DVI display card+sent card+receive card | PC+DVI display card+sent card+receive card |
| Average No Failure Time | ＞5000 hours | ＞5000 hours |
| Life-span | ＞100000 hours | ＞100000 hours |
| Out-of Control rate | ＜0.0001 | ＜0.0001 |
| Transmitting Distance | Internet cable:< 100m | Internet cable:< 100m |
FAQ:
1. Can you assign engineer to our site to guide the installation if
we require?
Yes. We have qualified and experienced engineers who are ready to
service for you.
2. How about your warranty and after-sale policy?
Two years warranty is free..
We provide 24 hour phone answering service and real-time remote
control service if you have any problem with our led screen.
3. How long time I can get the cargos after placing the order ?
Our production time is about 7~ 15 working days;
When we confirmed the order, after we get your deposit, we can
start production, we will update the production details in time;
Before finish, we will notice you and after we get full payment, we
can delivery the goods to you.
About the time from start port to destination, that depends on the
distance and the state of the sea company or airport company
4. What's the difference of DIP(1R1G1B) and DIP(3 in 1) ?
DIP(One LED, 3 in 1) LED Display, one pixel has one LED lamp, 3 led
chips in one LED Lamp;
Traditional DIP( 1R1G1B) use 3 LED Lamp in one pixel.
5. How I can make payment?
We support T/T, West Union and so on.
And about payment, we need you pay us 30% as deposit, for the rest
part, before delivery.
