Outdoor P10 led commercial advertising display
Features of led board display:
1. High quality LED chip and high anti-static electricity capacity.
2. Large viewing angle and smooth displaying provide excellent visual
effect from every angle.
3. The integration of lamp and driving IC,together with with the
multi-circuit structure,achievs evenly-distributed current,low
power consumption and fast heat dissipation.
4. Ultra high brightness,low attenuation,high reliability and weather
ability.
5. High contrast ratio.Adopting black lamps can improve the contrast
ratio by 50%.
6. High refresh rate,high gray scale,ghost-canceling,low power
consumption,low EMI,anti-creeping,multi-route redundancy
backup-supporting,and dot-by-dot-calibration.
Application scopes of led board display: Widely applied to traffic information distribution of station,
quay and airport, conference, shopping mall, brand presentantion,TV
station, stage show, concert and so on.
Specification of led board display:
| Item Name | P10 outdoor LED display |
| Item No. | P10 |
| LED Encapsulation | DIP 346 |
| Pixel Pitch | 10mm |
| Module Resolution(W*H) | 32dots *16dots |
| Module Size | 320*160mm |
| Cabinet size | 960mm x 960mm |
| Cabinet Resolution | 96dots(W) x 96dots(H) |
| Pixel Configuration | 1R1G1B(3 in1) |
| Pixel Density | 10000 pixel/m2 |
| Driving Method | Static Scan Mode |
| Refresh Frequency | ≥1500Hz(Supporting high refresh rate and depending on system
configuration) |
| Driving IC | Special constant current IC with high refresh rate and high gray
scale |
| Grey Scale | >14BIT(According to system and IC equipped) |
| White Balance Brightness | >6500cd/m2 |
| Color Temperature | 8000K ± 500(adjustable) |
| Viewing Angle | Horizontal Angle 100° Vertical Angle 50° |
| Optimal Viewing Distance | >10m |
| Working Voltage | DC4.2V |
| Max Power Consumption | 850W/m2(White Balance) |
| Avg Power Consumption | 390W/m2(Normal Working) |
| Lifetime | 50000 Hours |
| Operating Temperature | -20℃ ~60℃ |
| Weight | 45kg/pcs |
FAQ:
1. Are you factory?
Yes, we have very rich experience in production and development.
you will got better service and delivery on time.
2. How is your delivery time?
We delivery as contract on time, All kinds of led module have in
stock. We will be fine as compensation.
3. What is your products packing?
We provide 3 kinds of packing case: carton paper case,wooden
packing case and flight packing case.
Carton paper case for led module
Wooden packing case for heavy iron cabinet
Flight packing case for rental aluminum die-casting cabinet
4. Quality gurantee:
Life span of LED display screens is more than 100,000 hours
All our LED displays have CE,FCC,RoHS certificates.
5. Prompt &Professional service :
Any inquires will be replied within 24 hours in working days and
you’ll get helpful suggestions from us.
