Product Description
Features of P10 outdoor full color perimeter led display, stadium
led screen, football stadium perimeter led display screen:
1. High quality LED chip and high anti-static electricity capacity.
2. Large viewing angle and smooth displaying provide excellent
visual effect from every angle.
3. The integration of lamp and driving IC,together with with the
multi-circuit structure, achieves evenly-distributed current,low
power consumption and fast heat dissipation.
4. Ultra high brightness,low attenuation,high reliability and
weather ability.
5. High contrast ratio. Adopting black lamps can improve the
contrast ratio by 50%.
6. High refresh rate, high gray scale,ghost-canceling, low power
consumption, low EMI, anti-creeping, multi-route redundancy
backup-supporting,and dot-by-dot-calibration.
Applications:
LED display is applied for advertising, city beautifying,
information publicity, great concerns and relative activities.
1. Outdoor advertising, digital billboards, advertising in big
companies
2. Stadium, Sports halls, fields, playgrounds
3. Airports, bus stations and railway passenger terminals
4. Facades of shopping malls, department stores, banks and car
dealerships
5. Architecture and social projects, information systems in cities.
6. Show-business, concerts, festivals, motor shows and other public
events.
Paramters
| Module | Pitch/mm | P10 |
| Module size/mm | 320*160 |
| Density of pixel/(dots/m2) | 10000dots |
| Pixel composition | 1R1G1B |
| Led encapsulation | SMD3535 |
| Resolution of module | 32*16 |
| Screen | Optimum viewing distance | 10-150m |
| View angle / ° | 120H,120V |
| Max power consumption | 1000W/sqm |
| Size of cabinet/mm | 960X960 |
| Resolution of cabinet | 96*96 |
| Driving method | 1/4 scan |
| Refresh rate Hz/S | ≥960 |
| Luminance of white balance | ≥6500cd/sqm |
Operation of Environmental Temperature/℃ | below 30 to above 50 |
| Protective grade | IP65 |
| Working voltage | 110-220 VAC/+/- 10% |
| Grey scale/color | 14bits |
| Brightness adjustment | 4096 levels of each color(manually), |
| 100 levels of each color(automatically) |
| Input signal | RF,S-Video,RGB,RGBH,YUV,YC&Composition ,etc |
| Control system | Linsn / Nova(sending card, receiving cards and Hubs) |
| Average of non-failure life | >10,000h |
| Life span | >100,000h |
| Functionless dot rate | <0.0001 |
Trade Terms
1. Packing: Anti-shaking wooden cabinet /Air flight case/carton
2. Shipping port: Shenzhen. China
3. Shipping freights are quoted according to your requests
4. Delivery time:5-25 working days
5. 2 years warranty, lifelong maintaining.
After-sale service
1. Our products have two years warranty service ,lifetime free maintenance and upgrade.
2. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.
3. We offered training to our customer who includes operating and maintenance of our products.
4. In the Maintenance period of the LED screen body, free of all maintenance charges; After Maintenance period, only charge the material costs fees
free of manual work fees.
5. Full set of documents free of charge, which including installation guidance, software operation manual,
easy maintenance manual and control system software CD and so on.
6. If the users find any problem that cannot be solved, please
contact with our company, we can response in 24 hours. In order to
shorten the maintenance time, Our Company will deploy some spare
parts such as power and chips etc.
